NOTES: Power wiring may be brought into the unit through one of the knockouts in either the top or the right side panel.
Multiple knockouts are provided to accommodate all of the electric heat and transformer accessories that are available.
Use the knockouts that provide the best wire routing for the accessory being used.
024
024
024
Blower
Size
Coil
Model
GHC,
GFC,
GHT
Dimensions
Refrigerant*
Connections
Quick
Connect
Line
Sizes
A B C D E F G H J K L M Liquid Vapor Liquid Vapor
D10
024
16-1/4 1 12-1/8 3-7/8 12-1/8
14-1/4 22-3/4 54-1/2 3-1/2 1-1/2 1-3/4 3-1/2
F-6 F-11
5/16 5/8
030 14-1/4 22-3/4 54-1/2 3-1/4 6-3/8 14-7/8 16-7/8
5/16 3/4
D14
036
22-1/4 3-5/8 14-7/8 3-7/8 12-1/8
20-1/4 22-3/4 54-1/2 6 7-3/8 14-7/8 16-7/8
042 20-1/4 27-7/8 59-5/8 6 8-1/8 20 22
3/8 7/8
D20
048
26-1/4 5-5/8 14-7/8 3-7/8 12-1/8 24-1/4
27-7/8 59-5/8 8 6-3/4 20 22
060
60D**
061**
31-3/8 63-1/8 7-1/4 7-5/8 23-1/2 25-1/2
*
G*HT coils are available as sweat connect only.
**G*HT coil models only.
FIGURE 4 - DIMENSIONS
535.03-N1Y
4 Unitary Products Group
