York P2MP Series User Manual

Model Air Temp
Rise °F
Max.
Outlet
Temp.
°F
Blower Total
Unit
Amps
Max.
Over-
Current
Breaker
Min. Wire
Size
(AWG)
@ 75 Ft.
One Way
Recommended
High Velocity
Filter Size
Weight
(lbs)
HP Size
P2DPD10
*
04801
35 - 65 165 1/4 10 x 7 12.0 15 14 (2) 14 X 20 105
P2DPD12
*
06401
25 - 55 155 1/2 10 x 8 12.0 15 14 (2) 14 X 20 118
P2DPD12
*
08001
35 - 65 165 1/2 10 x 10 12.0 15 14 (2) 14 X 20 134
P2DPD16
*
08001
30 - 60 160 3/4 11 x 10 13.8 15 14 (2) 14 X 20 140
P2DPD16
*
09201
30 - 60 160 3/4 11 x 10 13.8 15 14 (2) 14 X 20 156
P2DPD20
*
10401
35 - 65 165 3/4 11 x 10 13.8 15 14 (2) 14 X 20 168
*
Model designator may be "N" for standard units, or "L" for factory built low NOx units
Model ABCD
P2DPD10
*
04801
16-1/4 14 15 3
P2DPD12
*
06401
16-1/4 14 15 4
P2DPD12
*
08001
22-1/4 20 21 4
P2DPD16
*
08001
22-1/4 20 21 4
P2DPD16
*
09201
22-1/4 20 21 4
P2DPD20
*
10401
26-1/4 24 25 4
All dimensions are in inches and are approximate.
C
3/4
28-1/2
A
20
40
FRONT LEFT SIDE
RIGHT SIDE
GAS INLET
1-1/4" X 2-1/2"
2
D
(Vent Connection)
5-3/4
2-1/2
ALT. GAS INLET
1-1/4" X 2-1/2"
T'STAT WIRING
7/8" K.O.
24
7-1/8
POWER WIRING
7/8" K.O.
IAMON
80
D
D
Vent Connection
D
(vent size)
20
C
FRONT
1-1/8
20
FRONT
1-1/8
B
A
TABLE 3 - RATINGS & PHYSICAL/ELECTRICAL DATA
FIGURE 2 - DOWNFLOW FURNACE DIMENSIONS
650.69-N3
Unitary Products Group 5
