York PCG6B48 - Page 13

5285473-UIM-E-1217
Johnson Controls Unitary Products 13
48100
High Cool
A 1851 1809 1781 1746 1707
1656 1609 1552 1518 1460
B 1689 1652 1630 1597 1556
1504 1461 1404 1368 1310
C 1614 1578 1554 1520 1477
1424 1382 1324 1286 1228
D 1374 1333 1298 1255 1204
1145 1100 1044 993 933
Low Cool
A 1473 1435 1406 1368 1320
1264 1220 1164 1119 1060
B 1374 1333 1298 1255 1204
1145 1100 1044 993 933
C 1322 1278 1238 1191 1138
1077 1030 975 920 859
D 1286 1241 1197 1149 1095
1032 984 930 872 810
High Heat
A 1704 1667 1645 1612 1572
1520 1477 1419 1384 1327
B 1506 1468 1441 1404 1358
1302 1259 1203 1159 1101
C 1322 1278 1238 1191 1138
1077 1030 975 920 859
D 1251 1205 1157 1107 1051
987 938 884 824 761
Low Heat
A 1392 1352 1318 1276 1226
1168 1123 1067 1017 957
B 1251 1205 1157 1107 1051
987 938 884 824 761
C 1139 1087 1027 968 907
839 785 733 663 598
D 984 922 841 769 700
625 564 515 430 361
48125
High Cool
A 1851 1809 1781 1746 1707
1656 1609 1552 1518 1460
B 1689 1652 1630 1597 1556
1504 1461 1404 1368 1310
C 1614 1578 1554 1520 1477
1424 1382 1324 1286 1228
D 1374 1333 1298 1255 1204
1145 1100 1044 993 933
Low Cool
A 1473 1435 1406 1368 1320
1264 1220 1164 1119 1060
B 1374 1333 1298 1255 1204
1145 1100 1044 993 933
C 1322 1278 1238 1191 1138
1077 1030 975 920 859
D 1286 1241 1197 1149 1095
1032 984 930 872 810
High Heat
A 2114 2046 1974 1914 1874
1815 1745 1696 1645 1582
B 1982 1930 1887 1844 1806
1752 1697 1643 1604 1545
C 1785 1746 1720 1687 1647
1596 1551 1494 1459 1402
D 1614 1578 1554 1520 1477
1424 1382 1324 1286 1228
Low Heat
A 2114 2046 1974 1914 1874
1815 1745 1696 1645 1582
B 1982 1930 1887 1844 1806
1752 1697 1643 1604 1545
C 1490 1452 1423 1386 1339
1283 1240 1183 1139 1080
D 1357 1315 1278 1234 1182
1123 1077 1021 969 908
60065
High Cool
A 2149 2114 2077 2030 1989
1948 1905 1859 1816 1768
B 2013 1977 1941 1898 1860
1816 1772 1726 1677 1630
C 1936 1900 1864 1822 1783
1739 1695 1649 1597 1551
D 1719 1685 1642 1600 1555
1508 1465 1418 1372 1327
Low Cool
A 1629 1591 1546 1502 1455
1409 1362 1315 1266 1220
B 1558 1516 1469 1423 1375
1329 1280 1232 1181 1135
C 1453 1406 1355 1305 1255
1207 1153 1100 1047 997
D 1410 1361 1307 1255 1204
1155 1100 1044 992 938
High Heat
A 1276 1219 1158 1098 1040
987 927 869 818 761
B 1133 1068 995 922 849
793 730 680 634 579
C 1025 950 868 788 713
654 591 505 458 415
D 844 748 651 563 494
433 372 168 115 105
Low Heat
A 1228 1169 1104 1039 976
922 861 806 757 700
B 1086 1017 940 863 786
728 664 617 573 519
C 844 748 651 563 494
433 372 168 115 105
D 786 666 593 514 453
370 314 263 180 38
Continued on next page. See end of Table 11 for NOTES.
Table 11: Airflow Performance - Side Duct Application (Continued)
Model Jumper Position
External Static Pressure (Inches WC)
0.1 0.2 0.3 0.4 0.5
0.6 0.7 0.8 0.9 1.0
SCFM SCFM SCFM SCFM SCFM
SCFM SCFM SCFM SCFM SCFM
