York YCAL0022EE User Manual

JOHNSON CONTROLS
FORM 150.67-EG1 (219)
38
Physical Data and Nominal Ratings
60HZ
MODEL YCAL00 19 22 28 33 43 46 52 56 66
Length, in 109.8 109.8 109.8 109.8 144.8 144.8 144.8 144.8 153.6
Width, in 44.7 44.7 44.7 44.7 90.6 90.6 90.6 90.6 90.6
Height, in 46.1 46.1 50 50 47.8 47.8 62.6 62.6 62.6
NOMINAL RATINGS
Tons 15.5 18.7 25.6 28.6 37.2 39.4 46.2 56.2 66.2
kW 18.3 22.2 30.4 32.6 44.2 46.6 54.6 66.7 76.8
EER, Btu/W.h 10.1 10.1 10.1 10.5 10.1 10.2 10.2 10.1 10.3
IPLV, Btu/W.h 14.7 15.5 13.7 14.5 14.5 14.7 15.1 14.7 15.5
REFRIGERANT R-410A
Number of Refrigerant Circuits 1 1 1 1 2 2 2 2 2
Refrig. Chg, Opt, R-410A (lb)
ckt1/ckt2
25 30 45 50 35/35 40/35 45/45 50/50 65/65
Oil Charge, gallons ckt1/ckt2 1.8 1.8 1.7 2.2 1.8/1.8 1.8/1.8 1.7/1.7 1.7/1.7 2.3/2.2
Shipping
Weight
Alum. Fin Coils, lb 1454 1567 1798 2034 2942 2968 3170 3206 4097
Copper Fin Coils, lb 1597 1781 2005 2240 3300 3326 3673 3685 4703
Operating
Weight
Alum. Fin Coils, lb 1481 1597 1835 2077 2967 3000 3208 3244 4142
Copper Fin Coils, lb 1624 1811 2035 2283 3325 3359 3710 3722 4748
NOMINAL COMPRESSOR CAPACITY
Compressor 1 8 10 15 15 10 12 13 15 20
Compressor 2 8 10 13 15 10 12 13 15 20
Compressor 3 – – – – – – – – –
Compressor 4 – – – – 10 10 13 15 15
Compressor 5 – – – – 10 10 13 15 15
Compressor 6 – – – – – – – – –
CONDENSER
Total Face Area, ft
2
34.7 34.7 43.5 43.5 87 87 116 116 128
Number of Rows Deep
Ckt. 1 2 3 3 3 2 2 3 3 3
Ckt. 2 – – – – 2 2 3 3 3
Fins per Inch 17 17 13 13 17 17 17 17 13
CONDENSER FANS, LOW SOUND
Number of Fans
Ckt. 1 2 2 2 2 2 2 2 2 2
Ckt. 2 – – – – 2 2 2 2 2
Fan Power, hp/fan 0.5 0.5 1.5 1.5 1.4 1.4 1.7 1.7 1.7
Fan rpm 1075 1075 1150 1150 1150 1150 1150 1150 1150
Total Chiller, cfm 11426 10670 24600 24600 47360 47360 52000 52000 52000
CONDENSER FANS, ULTRA QUIET
Number of Fans
Ckt. 1 2 2 2 2 2 2 2 2 2
Ckt. 2 – – – – 2 2 2 2 2
Fan Power, hp/fan – – 1.5 1.5 1.4 1.4 1.7 1.7 1.7
Fan rpm – – 820 820 820 820 820 820 820
Total Chiller, cfm – – 24600 24600 47360 47360 52000 52000 52000
EVAPORATOR
Water Volume, gal 1.2 1.2 1.2 1.2 2.7 2.7 3.5 3.5 3.5
Max Water Side Pressure, psig 300 300 300 300 300 300 300 300 300
Max Refrig Side Pressure, psig 450 450 450 450 450 450 450 450 450
Min. Chiller Water Flow, gpm 10 10 10 10 40 40 60 60 60
Max. Chiller Water Flow, gpm 150 150 150 150 200 200 300 300 300
Water Connection Size, in 2 2 2 2 3 3 3 3 3
