Maintenance and
Disassembly
Page 71
MOCA30U-18HN1-NB8, MOCA30U-24HN1-NB8 , MOD30U-36HN1-NB8, YUFE36BYSM-MO-1
Procedure Illustration
6) Disconnect the power transformer
(see CJ_ODU_010)
7) Disconnect the wires connected to
terminals. (see CJ_ODU_010)
8) Disconnect the wires connected to
contactor. (see CJ_ODU_010)
9) Disconnect the wires connected to
T3/T4 sensor. (see CJ_ODU_010)
CJ_ODU_010
Note: This section is for reference only. Actual unit appearance may vary.
To Next Page
