You-Q Luca - Table of Contents

Table of contents
Copyright
1. Introduction 5
1.1. Scope of this manual 5
1.2. Reference documentation 5
1.3. Symbols used in this manual 5
1.4. Guidelines and useful information for maintenance 6
1.5. Product identification 7
2. Warranty and Liability 8
2.1. Warranty 9
2.2. Liability 10
3. Safety 11
3.1. Maximum user weight reduction when EQLASS is installed on a Luca 11
3.2. Personnel qualifications 11
3.3. Cautions and warning statements 11
3.4. Pictograms on the wheelchair 13
4. Maintenance schedule & tooling 14
4.1. Overview of scheduled maintenance tasks 14
4.2. Mechanical tools 15
4.3. Electronical tools 16
4.4. Torque table 16
5. Maintenance tasks & adjustments 17
5.1. General preparations for maintenance 17
5.2. Carrier 19
5.2.1. Disassemble a motor arm 19
5.2.2. Replace a rubber suspension 19
5.2.3. Replace the carbon brushes 20
5.2.4. Replace a drive motor 20
5.2.5. Install a motor arm 21
5.2.6. Replace a drive wheel 21
5.2.7. Replace a castor wheel 22
5.2.8. Replace a castor fork 22
5.2.9. Replace the batteries 23
5.2.10. Replace main fuse 23
5.3. Interface (all types) 23
5.3.1. Adjust the position of the interface 23
5.3.2. Adjust the base height of the interface 24
5.4. Tilt-only interface 25
5.4.1. Replace the Tilt Actuator (Tilt-only Interface) 25
5.5. Tilt + lift interface 25
5.5.1. Replace the tilt actuator 25
5.5.2. Replace lift actuator 26
5.6. Legrests 26
5.6.1. Replace the actuator of a powered Legrest 26
5.6.2. Replace the gasspring of a comfort legrest 27
5.6.3. Replace the actuator of the central legrest 27
5.6.4. Replace the motor of the central legrest 28
Table of contents
3
