Page 8
09101-90(I)
05194 PROPELLER NUT WRENCH
08234 PROPELLER - 18CM X 30CM (BLACK PP)
05163PG FLANGE BEARING (2)
05160CS NOSE CONE (CONDUCTIVE)
05158 NOSE CONE O-RING
05161A 6-POLE MAGNET &
SHAFT COLLAR
09154
MAIN HOUSING AND
TAIL ASSY - SE
05138A
POTENTIOMETER COUPLING
05139
POT ADJUST THUMBWHEEL
09120 OPTICAL ENCODER
TRANSDUCER
05124VG (2)
VERTICAL SHAFT BEARING
05187 PROPELLER NUT 1/4-20
05164C PROPELLER SHAFT W/HUB
6-32 x 1/8 SET SCREW (5)
05127 MAIN HOUSING LATCH
6-32 x 3/8 FLAT HD SCREW
05126CS VERTICAL SHAFT
BEARING ROTOR (CONDUCTIVE)
05121E-10
JUNCTION BOX COVER
09124 SE PROCESSOR BOARD ASSY
4-40 x 5/16 SCREW (3)
05121E
MOUNTING POST ASSEMBLY
05129 BAND CLAMP
(INCL. W/ 05121E, 05128B)
05128B ORIENTATION RING
05165B FRONT BEARING CAP
R. M. YOUNG COMPANY
2801 Aero Park Drive , Traverse City, Michigan 49686 U.S.A.
TEL (231) 946-3980 FAX (231) 946-4772
GENERAL ASSEMBLY & REPLACEMENT PARTS
MODEL 09101 WIND MONITOR-SE
