Youngman BOSS X Series Instructions For Use

8
BoSS X-Series Instructions for Use
9
youngmangroup.com
2.1 TECHNICAL DATA
* Descent times include 3 seconds for the
intermediate stop on descent
BoSS X3X BoSS X3 BoSS X2
Rated load, manual forces and weight:
Safe working load 240kg
equivalent to 1 person, tools & materials
Maximum allowable manual force 200N (interior use only)
Maximum allowable chassis inclination 1.25
o
1.5
o
1.5
o
Maximum allowable wind speed 0m/s
Maximum load per wheel 450kg
Machine weight 390kg 349kg 313kg
Dimensions:
Maximum platform height 3.2m 2.55m 2.01m
Minimum platform height 0.695m 0.695m 0.6m
Maximum safe working height 5.2m 4.55m 4.01m
Platform delay on descent height 1.87m 1.85m 1.4m
Platform width 0.57m
Platform length 1.25m 1.05m 1.05m
Platform guardrail height 1.1m
Toeboard height 0.15m
Overall width 0.76m 0.7m 0.7m
Stowed height 1.8m 1.8m 1.7m
Stowed length 1.41m 1.21m 1.21m
Ground clearance 0.05m
Electrical:
Voltage 12V DC
Motor 1.2kW 1.2kW 0.8kW
Battery (deep cycle/sealed gel) 12V/100Ah 12V/100Ah 12V/80Ah
Battery charger Automatic multi voltage 110 and 240v
Hydraulics:
Maximum hydrauilic pressure 250 bar
Hydraulic fluid reservoir 2 litres
Performance:
Maximum number of lifts and descents on one
charge:
with 80kg platform load >325 >430 >565
with 240kg platform load >215 >225 >250
Ascent times:
with 80kg platform load 15 seconds 12 seconds 10 seconds
with 240kg platform load 18 seconds 15 seconds 12 seconds
Descent times*:
with 80kg platform load 21 seconds 17 seconds 15 seconds
with 240kg platform load 21 seconds 18 seconds 15 seconds
