Ytc YT-3400 SERIES User Manual

10 YT-3400/3450 series
2.5 Product Specification
Model
YT-3400/3450L
YT-3400/3450R
Acting Type
Single
Double
Single
Double
Input Signal
4~20mA DC
Minimum Current Signal
3.2mA(Standard), 3.8mA(Hart Included)
Supply Pressure
0.14~0.7 MPa (1.4~7 bar)
Stroke
10~150 mm
0~90°
Impedance
Max. 450Ω @ 20mA DC
Air Connection
PT, NPT 1/4
Gauge Connection
PT, NPT 1/8
Conduit Entry
PF(G) 1/2
Protection Grade
IP66
Explosion Proof
Ex db IIC T5/T6; Ex tb IIIC T100℃/T85℃
Ambient Temperature
T5
-40/-20℃ ~ 70℃ (-40/-4℉ ~ 158℉)
T6
-40/-20℃ ~ 80℃ (-40/-4℉ ~ 176℉)
Linearity
±0.5% F.S.
Hysteresis
0.5% F.S.
Sensitivity
±0.2% F.S
Repeatability
±0.3% F.S.
Flow Capacity
70 LPM (Sup.=0.14 MPa)
Air Consumption
0.01 LPM (Sup.=0.14 MPa @ idle)
Output Characteristic
Linear, Quick Open, EQ%, User Set (16 point)
Vibration
No Resonance upto 100Hz @ 6G
Humidity
5-95% RH @ 40℃
Communication (Option)
HART Communication
Feedback Signal (Option)
4~20mA (DC 10~30V)
Material
Aluminum (YT-3400) / Stainless stee 316 (YT-3450)
Weight
3.4kg (YT-3400) / 7.0 kg (YT-3450)
Painting
Epoxy Polyester Powder Coating (YT-3400)
Tested under ambient temperature of 20’C, absolute pressure of 760mmHg, and humidity of 65%. Please contact
Young Tech Co., Ltd for detailed testing specification. * Explosion proof certification is in progress.
