7
Cooler Space Requirements
Intel
Cooler Orientation
AMD
Installation Requirements
INTEL, AMD Loading Block
※
Caution
Recommended cooler orientation may differ according to the motherboard model.
※
Caution
Remove the tape cover of loading block and attach it to the backplate.
9
2
m
m
95m
m
130mm
Loading Block(Intel) Loading Block(AMD)
