Caution
Please make note of the Loading Block’s direction.
③ - ⓑ Socket 1155 / 1156 / 1366
Attach the Double-Sided Tape to the center of the Backplate and
remove the cover on the other side.
※ Sockets 1155 / 1156 / 1366 do not use the Loading Block.
③ - ⓐ Socket 775
Remove the tape covering film from the Loading Block’s surface and attach
to the Backplate.
Attach Double-Sided Tape to the installed Loading Block and remove the
other side’s cover.
Double-Sided Tape
Loading Block
To Next Page
