ZALMAN CNPS10X Flex - Page 9

8
.COM
ENGLISH
④ Remove the Clip Support attached to the motherboard.
M/B
M/B
③ Remove the tape covering film from the Loading Block’s surface and attach
to the Backplate.
Caution
Please make note of the Loading Block’s direction.
Attach the Double-Sided Tape to the installed Loading Block and remove
the other side’s cover.
Loading Block
Double-Sided Tape
O
X
