ZALMAN CNPS8700 LED User Manual

7
.COM
① Connect Fan Mate 2 between the
Fan Cable and the motherboard
as shown in the diagram below.
② Fan Mate 2 can be installed to the
side of the case using Double-Sided
Tape.
M/B
Fan Connector (Cooler)
Double-Sided Tape
6. Fan Mate 2 Installation and Usage
1) Fan Mate 2 Installation
2) Fan Mate 2 Operation
Adjust the Fan Speed Control
Knob for RPM control.
Fan Speed Control Knob
In the case that you get a BIOS error beep:
① Rotate the Fan Speed Control Knob clockwise to the maximum setting.
② Disable CPU Fan Detected in BIOS setting or set the system monitoring
program’s CPU Fan RPM to the lowest setting.
※ Certain motherboards will not boot if the CPU fan’s RPM is not detected. In this
case inquire to the motherboard’s manufacturer for additional details.
BIOS Booting Error
