ZALMAN CNPS9700 LED User Manual

3
.COM
4. Installation Requirements
1) Space Requirements
2) Air Guide Removal
3) Cooler Orientation
The cooler’s installation requires unobstructed space with dimensions of 127㎜
(width), 93㎜(length), 145㎜(height), and the CPU as a central reference point.
Please check if components such as ODDs and PSU protrude into the required
space.
Air guides on enclosures must be removed, before the cooler’s installation
, for
they protrude into the cooler’s required space.
It is recommended that the cooler be installed so that air flows from the cooler toward
the enclosure’s rear exhaust fan.
93㎜
145㎜
127㎜
PSU
