ZALMAN Z10 PLUS - Front Bezel; Removing the Side Panels; Mounting the Motherboard; Removing the Front Panel

8 9
Z10 SEIRES
1. Removing the side panels
I/O Ports
# Part # Part # Part # Part
ⓐ Power Button ⓑ Reset Button ⓒ HDD / Power LED ⓓ Headphone Jack
ⓔ Microphone Jack ⓕ USB 3.0 Ports ⓖ Type-C ⓗ Led Button
2. Removing the front panel 2-1 Removing the front dust lter
2-2. Front Bezel
3. Mounting the motherboard
Motherboard Stando
SSD / MB Screw
ⓐ ⓑ ⓒ ⓓ ⓔ ⓕ ⓖ ⓗ
