6
Z9 U3
②
Attach Drive to Tray
A. 3.5” FDD Installation
3.5” FDD
Bolt B
C. 2.5” SSD Installation
SSD
Bolt B
B. 3.5” HDD Installation
3.5” HDD
Bolt A
(4) Front Cover Installation
When removing the front cover, the power switch and extension
cable are separated to prevent disconnection. Be sure to connect
them before installing the front cover.
