Zamboni 525 - Option CE; Options CG, CN

Option CE
Electronic displacement control (EDC)
177.8 max.
[7.00]
124.2 max.
[4.89]
Si d e v i e w
Var i ab l e p u m p w i t h EDC
(Packard Weather-Pack connector)
View X
Fr o n t v i e w
Var i ab l e p u m p w i t h EDC
(Packard Weather-Pack connector)
Packard "Weather Pack" shroud connector
on 76 mm [3 in] lead wires
4-way (Dual Co il PCP) mates with Packard 12015797 connector
X
A
B
C
D
Danfoss
mating parts kit
part no.K0338 4
(female terminals)
V
View V
P10 0632
Packard Weather-Pack
4-way tower connector
(male terminals)
A
B
C
D
Options CG, CN
Electronic displacement control (EDC)
138.4 [5.45]
Si d e v i e w
Ta n d e m p u m p w i t h ED C
(MS connector)
124.2 max.
[4.89]
332.0 [13.07]
124.2 max.
[4.89]
U
View U
97.5
[3.84]
141.7
[5.58]
7/8 - 20 UNEF
MS53102C connector
mates with MS3106E-14S-2S
connector
7/8 - 20 UNEF
MS53102C connector
mates with MS3106E-14S-2S
connector
Pu mp
P10 8516
CG
CN
1
2
Deutsch Connect or
Technical Information Series 40 M46 Pumps
Control Options - Installation Drawings
62 L1001029 • Rev BG • May 2015
