INSTALLATION,
OPERATION
&
MAINTENANCE
MANUAL
AIR COOLED CONDENSING UNITS
CX SERIES (CX150 - CX360)
Part Number: 800-213-58 (Rev.-02)

Table of Contents

Questions and Answers

  • J
    Jennifer MillsAug 13, 2025
    What to do if Zamil Air Conditioner compressor will not start, hums but trips on overload protector?
    • J
      Jonathan ShortAug 13, 2025
      If your Zamil Air Conditioner compressor hums but trips on the overload protector, the following could be the cause: * **Improperly wired:** Check the wiring against the diagram. * **Low voltage to unit:** Determine the reason and correct it. * **Starting capacitor defective:** Determine the reason and replace it. * **Relay failing to close:** Determine the reason and correct it; replace if necessary. * **Compressor motor has a winding open or shorted:** Replace the compressor. * **Internal mechanical trouble in compressor:** Replace the compressor. * **Liquid refrigerant in compressor:** Check the crank case heater. * **High discharge pressure:** Unequilized pressure in the system.
  • R
    raymondjonesAug 17, 2025
    Why does my Zamil Air Conditioner unit operate continuously?
    • R
      Robert HortonAug 17, 2025
      If your Zamil Air Conditioner operates continuously, here are some potential causes and solutions: * **Shortage of refrigerant:** Fix the leak and add refrigerant. * **Control contacts stuck or frozen closed:** Clean the contacts or replace the control. * **Refrigerated or air-conditioned space has excessive load or poor insulation:** Determine the fault and correct it. * **System inadequate to handle:** Replace with a larger system. * **Evaporator coil iced:** Defrost the coil. * **Restriction in the refrigeration system:** Determine the location and remove the restriction. * **Dirty condenser:** Clean the condenser. * **Filter dirty:** Clean or replace the filter.
  • R
    Robert LynchAug 21, 2025
    Why is the evaporator icing up in my Zamil Air Conditioner?
    • C
      Carrie HuntAug 21, 2025
      If the evaporator in your Zamil Air Conditioner is icing up, consider the following possible causes and solutions: * **Restricted airflow:** Check for dirt or lint on the coil. * **Dirty air filter:** Clean or replace the air filter periodically. * **Short of refrigerant:** Check the system pressure, take a superheat reading, and add refrigerant as needed. * **Low air volume:** Check for a dirty air filter or loose belt. * **Restricted distributor tube:** Check for a warm distributor tube. * **Restricted liquid line/low liquid line pressure:** Check for restrictions in the lines and improve liquid line pressure by proper charging or installing a fan cycling switch, etc.
  • M
    Megan HannaAug 26, 2025
    What causes my Zamil Air Conditioner unit to run OK, but short cycles frequently?
    • C
      Christopher KellyAug 26, 2025
      If your Zamil Air Conditioner unit runs okay but short cycles frequently, here’s what might be happening: * **Overload protector:** Check the cause. * **Thermostat:** If the differential is set too close, widen it. * **High pressure cut-out due to:** * Insufficient air: Check airflow to the condenser and correct it. * Overcharge: Reduce the refrigerant charge. * Air in system: Purge the system. * **Low pressure cut-out due to:** * Undercharge: Fix any leaks and add refrigerant. * Restriction in expansion device: Replace the device.
  • A
    Austin CrawfordAug 29, 2025
    Why Zamil Air Conditioner compressor starts, but does not switch off the start winding?
    • S
      steelejaclynAug 29, 2025
      If your Zamil Air Conditioner compressor starts but does not switch off the start winding, here are potential causes: * **Improperly wired:** Check the wiring against the diagram. * **Low voltage to unit:** Determine the reason and correct it. * **Relay failing to open:** Determine the reason and correct it; replace if necessary. * **Run capacitor defective:** Determine the reason and replace it. * **Excessively high discharge pressure:** Check the discharge shut off valve; there may be a possible overcharge, or insufficient cooling on the condenser. * **Compressor motor has a winding open or shorted:** Replace the compressor. * **Internal mechanical trouble in compressor stuck up or frozen:** Replace the compressor.
  • L
    lcainNov 3, 2025
    How to fix Zamil Air Conditioner compressor that will not start, no hum?
    • G
      George MartinNov 3, 2025
      If your Zamil Air Conditioner compressor won't start and there's no humming sound, here are several potential causes and solutions: * **Line disconnect switch open:** Close the start or disconnect switch. * **Fuse removed or blown:** Replace the fuse. * **Overload protector tripped:** Refer to the electrical section for guidance. * **Control stuck in open position:** Repair or replace the control. * **Control off due to cold location:** Relocate the control. * **Wiring improper or loose:** Check the wiring against the diagram. * **Thermostat defective or improperly installed:** Replace or relocate the thermostat. * **Control circuit open:** Trace the control circuit with the wiring diagram and repair it. * **Burned/open circuit motor winding:** Replace the compressor wit...
  • B
    bakerjamesNov 7, 2025
    Why does my Zamil Air Conditioner compressor start and run, but short cycles on overload protector?
    • M
      Mr. Kenneth Cervantes DDSNov 7, 2025
      If the compressor in your Zamil Air Conditioner starts and runs but short cycles on the overload protector, consider these possibilities: 1. **Additional current passing through overload protector:** Check the wiring diagram and inspect for added fan motors or pumps connected to the wrong side of the protector. 2. **Low voltage to unit (or unbalanced if three phase):** Determine the reason and correct it. 3. **Overload protector defective:** Check the current and replace the protector if necessary. 4. **Run capacitor defective:** Determine the reason and replace it. 5. **Excessive discharge pressure:** Check airflow across the condenser coil and look for restrictions in the refrigeration system. 6. **Suction pressure too high:** Check for the possibility of misapplication and consid...

Summary

Introduction and Safety Information

Safety Hazard Levels

Details on Warning and Caution levels, emphasizing respect for safety identifications.

Installation Procedures

General Installation Guidelines

Unit Location and Site Preparation

Rigging and Mounting

Rigging Instructions

Guidance for riggers on using slings, spreader bars, and protecting unit components during lifting.

Mounting and Drainage

Refrigerant Systems

Piping Connections and Specifications

Leak Testing and Refrigerant Charging

Procedures for leak detection and proper refrigerant charging.

Electrical Systems

Power and Control Wiring

Requirements for power supply, control wiring, and grounding.

Wiring Diagrams - CX150, CX180-CX220, CX240-CX360 Series

CX180-CX220 Dual Compressor Wiring

CX240-CX360 Dual Compressor Wiring

Operation Instructions

Pre-Startup Inspection Checklist

Essential checks before system operation, covering all components and connections.

Maintenance Overview and Safety

Principles of regular maintenance, monthly tasks, and critical electrical safety warning.

Preventive Maintenance Schedule and Tools

Maintenance Schedule and Checks

Troubleshooting Common Issues

Compressor Start and Overload Problems

Diagnosing issues like compressor not starting, tripping on overload, or short cycling.

Unit Cycling and Continuous Operation

Troubleshooting Advanced Issues

Pressure and Oil Level Issues

Temperature and Line Issues
