INSTALLATION,
OPERATION
&
MAINTENANCE
MANUAL
AIR COOLED CONDENSING UNITS
CX SERIES (CX150 - CX360)
Part Number: 800-213-58 (Rev.-02)

Table of Contents

Questions and Answers

  • S
    Sarah MoodyAug 12, 2025
    What to do if Zamil Air Conditioner compressor will not start, hums but trips on overload protector?
    • C
      Cheryl HughesAug 13, 2025
      If your Zamil Air Conditioner compressor hums but trips on the overload protector, the following could be the cause: * **Improperly wired:** Check the wiring against the diagram. * **Low voltage to unit:** Determine the reason and correct it. * **Starting capacitor defective:** Determine the reason and replace it. * **Relay failing to close:** Determine the reason and correct it; replace if necessary. * **Compressor motor has a winding open or shorted:** Replace the compressor. * **Internal mechanical trouble in compressor:** Replace the compressor. * **Liquid refrigerant in compressor:** Check the crank case heater. * **High discharge pressure:** Unequilized pressure in the system.
  • P
    Paul CoxAug 17, 2025
    Why does my Zamil Air Conditioner unit operate continuously?
    • L
      Luke LaneAug 17, 2025
      If your Zamil Air Conditioner operates continuously, here are some potential causes and solutions: * **Shortage of refrigerant:** Fix the leak and add refrigerant. * **Control contacts stuck or frozen closed:** Clean the contacts or replace the control. * **Refrigerated or air-conditioned space has excessive load or poor insulation:** Determine the fault and correct it. * **System inadequate to handle:** Replace with a larger system. * **Evaporator coil iced:** Defrost the coil. * **Restriction in the refrigeration system:** Determine the location and remove the restriction. * **Dirty condenser:** Clean the condenser. * **Filter dirty:** Clean or replace the filter.
  • D
    Danielle Lucas MDAug 21, 2025
    Why is the evaporator icing up in my Zamil Air Conditioner?
    • G
      Gina MartinezAug 21, 2025
      If the evaporator in your Zamil Air Conditioner is icing up, consider the following possible causes and solutions: * **Restricted airflow:** Check for dirt or lint on the coil. * **Dirty air filter:** Clean or replace the air filter periodically. * **Short of refrigerant:** Check the system pressure, take a superheat reading, and add refrigerant as needed. * **Low air volume:** Check for a dirty air filter or loose belt. * **Restricted distributor tube:** Check for a warm distributor tube. * **Restricted liquid line/low liquid line pressure:** Check for restrictions in the lines and improve liquid line pressure by proper charging or installing a fan cycling switch, etc.
  • D
    David MckinneyAug 26, 2025
    What causes my Zamil Air Conditioner unit to run OK, but short cycles frequently?
    • C
      campbellmaryAug 26, 2025
      If your Zamil Air Conditioner unit runs okay but short cycles frequently, here’s what might be happening: * **Overload protector:** Check the cause. * **Thermostat:** If the differential is set too close, widen it. * **High pressure cut-out due to:** * Insufficient air: Check airflow to the condenser and correct it. * Overcharge: Reduce the refrigerant charge. * Air in system: Purge the system. * **Low pressure cut-out due to:** * Undercharge: Fix any leaks and add refrigerant. * Restriction in expansion device: Replace the device.
  • C
    Carol KentAug 30, 2025
    Why Zamil Air Conditioner compressor starts, but does not switch off the start winding?
    • S
      sosalisaAug 30, 2025
      If your Zamil Air Conditioner compressor starts but does not switch off the start winding, here are potential causes: * **Improperly wired:** Check the wiring against the diagram. * **Low voltage to unit:** Determine the reason and correct it. * **Relay failing to open:** Determine the reason and correct it; replace if necessary. * **Run capacitor defective:** Determine the reason and replace it. * **Excessively high discharge pressure:** Check the discharge shut off valve; there may be a possible overcharge, or insufficient cooling on the condenser. * **Compressor motor has a winding open or shorted:** Replace the compressor. * **Internal mechanical trouble in compressor stuck up or frozen:** Replace the compressor.
  • T
    Timothy Long PhDNov 3, 2025
    How to fix Zamil Air Conditioner compressor that will not start, no hum?
    • J
      Jordan Hamilton DDSNov 3, 2025
      If your Zamil Air Conditioner compressor won't start and there's no humming sound, here are several potential causes and solutions: * **Line disconnect switch open:** Close the start or disconnect switch. * **Fuse removed or blown:** Replace the fuse. * **Overload protector tripped:** Refer to the electrical section for guidance. * **Control stuck in open position:** Repair or replace the control. * **Control off due to cold location:** Relocate the control. * **Wiring improper or loose:** Check the wiring against the diagram. * **Thermostat defective or improperly installed:** Replace or relocate the thermostat. * **Control circuit open:** Trace the control circuit with the wiring diagram and repair it. * **Burned/open circuit motor winding:** Replace the compressor wit...
  • D
    dixonkeithNov 7, 2025
    Why does my Zamil Air Conditioner compressor start and run, but short cycles on overload protector?
    • S
      shawkellyNov 8, 2025
      If the compressor in your Zamil Air Conditioner starts and runs but short cycles on the overload protector, consider these possibilities: 1. **Additional current passing through overload protector:** Check the wiring diagram and inspect for added fan motors or pumps connected to the wrong side of the protector. 2. **Low voltage to unit (or unbalanced if three phase):** Determine the reason and correct it. 3. **Overload protector defective:** Check the current and replace the protector if necessary. 4. **Run capacitor defective:** Determine the reason and replace it. 5. **Excessive discharge pressure:** Check airflow across the condenser coil and look for restrictions in the refrigeration system. 6. **Suction pressure too high:** Check for the possibility of misapplication and consid...

Summary

Installation Procedures

Location of Unit

Points to consider when selecting the unit's placement for optimal performance and safety.

Jobsite Conditions

Checks for proper dimensions and clearances at the job site for unit installation.

Rigging and Mounting

Attention to Riggers

Instructions for personnel involved in rigging operations to ensure safe handling.

Maintenance

Monthly Inspection

Regular inspection of unit external surfaces and control panel for operational checks.

Coil Cleaning

Procedures for cleaning condenser coils using approved methods and tools.

Compressor Maintenance

Visual checks for oil leakage and electrical connections for compressor health.

Operation Instructions

Pre-Startup Inspection and Check List

Steps to cover before switching the system on for operation after installation.
