Zamil PS360 - User Manual

Questions and Answers

A
Angel MarksNov 23, 2025
What to do if Zamil Air Conditioner blower is running, but with not enough supply air?
- D
  ddavisNov 24, 2025
  If your Zamil Air Conditioner's blower is running but not delivering enough air, it could be due to several reasons: * **Loose Belt:** The belt may be loose. Adjust it and check the belt tension. * **Variable Pulley:** The variable pulley might be wide open. Adjust the pitch of the pulley. * **Return Air Obstruction:** There might be an obstruction in the return air path. Check for and remove any obstructions. * **High Static Pressure:** The static pressure might be too high. Verify the static pressure and fan performance data. * **Improper Pulley:** The pulley selection might be incorrect. Change the pulley, but only if the blower motor ampere is within the rated load. * **Dampers/Air Balance:** Dampers might be closed or the air balance might be improper. Ensure all dampers ...
L
lsmithAug 23, 2025
Why does my Zamil Air Conditioner compressor keep short cycling?
- C
  Cynthia CastanedaAug 23, 2025
  If your Zamil Air Conditioner's compressor runs but cycles on and off frequently, consider these potential causes: * **Safety Circuit:** The safety circuit might be opening due to low suction pressure, high discharge pressure, or an overload protector. You should verify the reasons for these issues. * **Thermostat Location:** The thermostat might be in a cold location. Check its placement and relocate if necessary. * **Thermostat Setting:** The thermostat setting might be too high. Try lowering the temperature setting to 21°C for testing.
J
Joshua GarciaAug 27, 2025
Why is my Zamil Air Conditioner not sufficiently cooling during daytime?
- N
  Nicholas PatelAug 27, 2025
  If your Zamil Air Conditioner unit is not cooling properly during the daytime, here are a few things to check: * **High Discharge Pressure:** Verify the reason for high discharge pressure. * **Thermostat Setting:** Ensure the thermostat is set correctly; adjust it if needed. * **Serving Area:** The unit might be serving too large of an area; check the design and unit selection. * **Less Air Quantity:** Verify the reason for insufficient air quantity. * **High Ambient Condition:** Check the ambient conditions. * **Dirty Condenser:** Clean the condenser.
S
stephen76Aug 27, 2025
What causes Zamil Air Conditioner compressor not working?
- C
  Christopher RobertsAug 27, 2025
  If your Zamil Air Conditioner's compressor is not working, consider the following potential causes: * **Low Voltage:** The voltage might be too low. Rectify the reason and correct it. * **Single Phase Failure:** There might be a single-phase failure. Check the compressor amperage for each phase. * **Burned Wiring:** The wiring might be burned. Check and correct it. * **Overload Protector:** The overload protector might be open. Check and verify the reason. * **Defective Contactor:** The contactor might be defective. Check and replace it. * **Burned Compressor Motor Winding:** The compressor motor winding might be burned. Check and replace it. * **Damaged Compressor:** The compressor might be damaged or stuck. Check and replace it.
J
James GarciaAug 29, 2025
Why is the cooling coil ices up in my Zamil Air Conditioner?
- J
  julia05Aug 29, 2025
  If your Zamil Air Conditioner's cooling coil is icing up, here's what could be happening: * **Less Freon:** There might be a Freon leak. Check for leaks and charge Freon as required. * **Less Air Quantity:** There might be insufficient air quantity. Determine the reason and correct it. * **Dirty Filter:** The filter might be dirty. Clean it. * **Dirty Cooling Coil:** The cooling coil itself might be dirty. Clean it.
T
Taylor AdamsSep 23, 2025
Why Zamil Air Conditioner taking more time for the pumpdown cycle, cooling coil ices up?
- C
  charleshowardSep 23, 2025
  If your Zamil Air Conditioner is taking more time for the pumpdown cycle and the cooling coil is icing up, it could be due to a leaky pumpdown solenoid valve. Check the pumpdown solenoid valve and replace it if necessary.
G
gregorykathleenSep 16, 2025
Why does Zamil Air Conditioner compressor goes lockout?
- J
  Jonathan KruegerSep 16, 2025
  If your Zamil Air Conditioner's compressor goes into lockout (pump down system), it could be due to: * **Imbalance Freon:** Check the Freon charge and confirm the Full Load Amperage (FLA). * **Malfunctioning Pumpdown Solenoid Valve:** Check the operation of the pumpdown solenoid valve.
W
woodnathanSep 18, 2025
Why Zamil Air Conditioner unit operational noise listening inside the building?
- R
  robertsleahSep 18, 2025
  If your Zamil Air Conditioner has unit operational noise listening inside the building, here are some things to check: * **Improper Installation:** Check and correct the installation. * **Improper Vibration Isolators:** Check and correct the vibration isolators. * **Abnormal Noise:** Verify the reason for the noisy unit and correct it. * **Unit Proximity:** Verify the design and relocate the unit if necessary. * **Duct Design:** Check and verify the duct design. * **Wooden Packing:** Remove any wooden packing beneath the compressor.
J
jtorresSep 8, 2025
What causes Zamil Air Conditioner blower to delivers excess air?
- K
  Karen KnoxSep 8, 2025
  If your Zamil Air Conditioner's blower is running and delivering too much air, it could be due to: * **Variable Pulley:** The variable pulley might need tightening. Adjust the pitch of the pulley. * **Improper Pulley/Motor Selection:** The pulley or motor selection might be unsuitable. Select a suitable combination. * **Low External Static Pressure:** The external static pressure might be low. Check the duct design.
R
Rachel DillonSep 5, 2025
Why Zamil Air Conditioner thermostat LCD panel display is not bright?
- J
  Jeffrey ThomasSep 5, 2025
  If the thermostat LCD panel display of your Zamil Air Conditioner is not bright and doesn't function properly, it's likely that the battery life is over. Replace the battery.
