Zamil PS360 - Model Decoding; PS036 - PS060 Direct Drive Motor Models; PS075 - PS360 Belt Driven Motor Models

C : 1.5 HP ODP D : 2 HP ODP D : 2 HP ODP E : 3 HP ODP F : 3 HP TEFC G : 5 HP ODP H : 5 HP TEFC J : 7.5 HP ODP K : 7.5 HP TEFC J : 7.5 HP ODP K : 7.5 HP TEFC L : 10 HP ODP M : 10 HP TEFC L : 10 HP ODP M : 10 HP TEFC N : 15 HP ODP P : 15 HP TEFC
MODELS: PS075 - PS360 (BELT DRIVEN MOTOR)
1& 2
BASIC
3, 4 & 5
NOMINAL COOLING
CAPACITY
(MBH)
8
BLOWER
MOTOR
6
ELECTRICAL
SUPPLY
( V-Ph-Hz )
10
HEATER
OPTIONS
(kW/STAGE)
12
CONDENSER
COIL
PS
PACKAGED
UNIT
036 048 060
U : 0.5 HP ODP
W : 0.75 HP ODP
H : 208/230-3-60 M: 380-3-60 (4 WIRE) F : 460-3-60
N : NO HEATER A : 5/1 B : 6/1 C : 7.5/1 D : 10 /2 E : 12/2
J : IGT + ENHANCED
AL. FINS
K : IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
9
DRIVE
OPTIONS
N : DIRECT
DRIVE
11
EVAPORATOR
COIL
J : IGT + ENHANCED
AL. FINS
K :IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
15
UNIT
ACCESSORIES
N : STANDARD UNIT C :FRESH AIR
MANUAL DAMPER
MODELS: PS036 - PS060 (DIRECT DRIVE MOTOR)
MODEL DECODING
7
REFRIGERA-
TION CIRCUIT
S : SINGLE
14
OTHER
OPTIONS
N : STANDARD UNIT I : ANTI-ICE U :UVM V : VOLT FREE
CONTACT
13
PDS
OPTION
N : NO PDS
OPTION
P : PDS OPTION
1& 2
BASIC
3, 4 & 5
NOMINAL COOLING
CAPACITY
(MBH)
8
BLOWER
MOTOR
6
ELECTRICAL
SUPPLY
( V-Ph-Hz )
10
HEATER
OPTIONS
(kW/STAGE)
12
CONDENSER
COIL
PS
PACKAGED
UNIT
075 090 100 120 180 215 240 300 360
H : 208/230-3-60 M: 380-3-60 (4 WIRE) F : 460-3-60
N : NO HEATER A : 5/1* B : 6/1* C : 7.5/1 D : 10 /2 E : 12/2 F : 15 /2 G : 20 /2 C : 7.5/1 D : 10 /2 E : 12/2 F : 15 /2 G : 20 /2 H : 25/2 J : 30/2**
J : IGT + ENHANCED
AL. FINS
K : IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
9
DRIVE
OPTIONS
J : ALT. I K : ALT. II
11
EVAPORATOR
COIL
J : IGT + ENHANCED
AL. FINS
K :IGT + ENHANCED
MHG. FINS
L : IGT + CORRU-
GATED CU. FINS
15
UNIT
ACCESSORIES
N : STANDARD UNIT C :FRESH AIR
MANUAL DAMPER
7
REFRIGERA-
TION CIRCUIT
S : SINGLE
14
OTHER
OPTIONS
N : STANDARD UNIT I : ANTI-ICE U :UVM V : VOLT FREE
CONTACT
13
PDS
OPTION
N : NO PDS
OPTION
P : PDS OPTION
NOTE:
*
– Applicable for PS075 models only.
**
– Applicable for models PS180 & above only.
D :DUAL
