PL-OM-CNX-07-1M-E
INSTALLATION,
OPERATION
&
MAINTENANCE
MANUAL
AIR COOLED CONDENSING UNITS
'CNX' SERIES

Table of Contents

Questions and Answers

  • A
    Amanda ParkerAug 7, 2025
    What to do if Zamil Air Conditioner compressor will not start – hums but trips on overload protector?
    • S
      sboydAug 7, 2025
      If your Zamil Air Conditioner's compressor hums but trips the overload protector, consider these potential causes and solutions: * Check the wiring against the diagram to ensure it is properly wired. * Low voltage to the unit could be the issue. Determine the reason for the low voltage and correct it. * The relay might be failing to close. Determine the reason and correct it; replace the relay if necessary. * The compressor motor may have an open or shorted winding, requiring compressor replacement. * There could be internal mechanical trouble within the compressor, also requiring replacement. * Liquid refrigerant in the compressor can cause this. Check the crankcase heater. * High discharge pressure, indicating unequalized pressure in the system, might be the problem.
  • M
    Michael LawrenceAug 13, 2025
    How to fix a Zamil Air Conditioner compressor that will not start – no hum?
    • A
      Adam ShafferAug 13, 2025
      If your Zamil Air Conditioner compressor isn't starting and there's no humming sound, here's what you can check: * Ensure the line disconnect switch is closed to start or disconnect the switch. * If the overload protector has tripped, refer to the electrical section. * If the control is stuck in the open position, repair or replace it. * If the control is off due to a cold location, relocate it. * Verify the wiring against the diagram to ensure it's correct and not loose. * If the thermostat is defective or improperly installed, replace or relocate it. * If the control circuit is open, trace it with the wiring diagram and repair it. * If the motor winding is burned or open circuit, replace the compressor with all precautions.
  • K
    Kathleen LozanoAug 19, 2025
    Why is the suction line frosted or sweating on my Zamil CNX150?
    • S
      Sara VegaAug 19, 2025
      The suction line of your Zamil Air Conditioner may be frosted or sweating due to: * The expansion valve passing excess refrigerant or being oversized. Readjust the valve or replace it with a smaller one. * The expansion valve being stuck open. Clean the valve of any foreign particles, and replace it if necessary. * The evaporator fan not running. Determine the reason and correct it. * An overcharge of refrigerant. Correct the charge.
  • C
    Christopher BrownAug 25, 2025
    What causes a liquid line to frost or sweat on a Zamil CNX150 Air Conditioner?
    • J
      Jessica HansonAug 26, 2025
      If the liquid line on your Zamil Air Conditioner is frosted or sweating, it could be due to: * A restriction in the dehydrator or strainer. Replace the part. * The liquid shut-off valve being partially closed. Open the valve fully.
  • J
    joseph88Oct 31, 2025
    Why does my Zamil Air Conditioner compressor start and run, but short cycles on overload protector?
    • K
      kristen51Oct 31, 2025
      This issue may arise due to several reasons: * There might be additional current passing through the overload protector. To solve this, check the wiring diagram and inspect for added fan motors or pumps connected to the wrong side of the protector. * Low voltage to the unit (or unbalanced if three phase) can be a cause. You should determine the reason and correct it. * The overload protector itself may be defective. In this case, check the current and replace the protector if necessary. * Excessive discharge pressure may be the reason. Check airflow across the condenser coil and look for restrictions in the refrigeration system. * High suction pressure may cause the issue. Check for the possibility of misapplication and consider using a stronger unit. * The compressor might be...

Summary

MODEL DECODING

PHYSICAL DATA

ELECTRICAL DATA

DIMENSIONS

CNX 150 - CNX 420 Dimensions

Diagrams showing dimensions for CNX 150 to CNX 420 models.

CNX 480 - CNX 840 Dimensions

Diagrams showing dimensions for CNX 480 to CNX 840 models.

CNX M-Series Dimensions

Diagrams showing dimensions for CNX M-series models.

MICROPROCESSOR CONTROL SYSTEM

Controller Hardware Overview

Description of the User Interface, Main, and Auxiliary Boards.

LCD Display Information

Data displayed on the LCD panel during operation.

System Protection Features

Overview of protective devices and settings for safe operation.

USER SEQUENCE OF OPERATION

Starting and Shutting Down the Unit

Step-by-step guide for machine start-up and shutdown.

Changing Set Points

Procedure for modifying unit set points via the control panel.

Compressor and Blower Motor Control

How compressors and blower motors are controlled.

SCHEMATIC WIRING DIAGRAM

TYPICAL HIGH AND LOW VOLTAGE FIELD WIRING CONNECTIONS

RIGGING INSTRUCTIONS

LOAD DISTRIBUTION

INSTALLATION INSTRUCTIONS

Unit Location and Piping

Guidelines for unit placement and refrigerant piping connections.

Leak Testing and Refrigerant Charging

Procedures for leak testing and charging the refrigerant system.

Field Wiring

Guidelines for electrical field wiring connections.

Start-Up Inspection and Checklist

Pre-operation inspection checklist before system operation.

Operational Start-Up Procedure

Steps for verifying and initiating unit operation.

ELECTRICAL

Power Supply and Unbalanced Voltage

Requirements for power supply and addressing voltage unbalance.

Component Protection and Control

Functions of contactors, motors, heaters, and voltage monitors.

REFRIGERATION

Compressor Types and Characteristics

Overview of semi-hermetic, twin screw, and scroll compressors.

System Protection and Troubleshooting

Burn out procedures, contamination sources, and pressure switches.

Compressor Protection Controls

Details on low pressure protection and pump down control.

TROUBLE SHOOTING CHART

PARTS LIST

RECOMMENDED SPARE PARTS

PREVENTIVE MAINTENANCE SCHEDULE

MATERIAL SAFETY DATA SHEET

Health Hazards and Precautions

Information on toxicity, contact, and inhalation hazards of R134a.

Handling, Storage, and Spill Procedures

Guidelines for safe handling, storage, spills, and disposal.

PRESSURE TEMPERATURE CHART, R-134 a
