Zanotti BGM11202F - General Characteristics and Consumption; MDB235 NO...; GCD401 NO... Specifications; MDB235 TO...; GCD401 TO... Specifications; BDB235 NO...; HCD401 NO... Specifications

DATA:
REV.nr. FOGLIO nr :
DI
33
MDB235NO...
MDB253TO...
BDB235NO...
AA08001
04-04-2003Soncini
DISEGNO nr.
ApprovatoDisegnato
Soncini
DATA: Approvato
MODELLO
GCD401NO...
GCD401TO...
HCD401NO...
EVAPORATORCONDENSING UNIT
TO X3
TO X2
TO X2
FROM X1
FROM X1
FROM X1
RIGHT
LEFT
MTZ32JF4=MT32JF4=5,9 A max.
MTZ40JH4=MT40JH4=10,0 A max.
MDB235NO... (GCD401NO...)
MDB235TO... (GCD401TO...)
4 x 1,5 mmq
5 x 2,5 mmq
CAVO DI LINEA
( LINE CABLE )
COMPRESSORE
(COMPRESSOR)
MACCHINA
( UNIT )
CAVO COMPRES.
(COMPRES. CABLE)
VENTOLA COND. VENTOLE EVAP.
(CONDEN. FAN) (EVAP. FANS)
SBRINAMENTO
(DEFROST)
I max.=6,8 A
I max.=6,8 A
In=0,73 A In tot.=1,24 A
In=0,73 A In tot.=1,24 A
CARATTERISTICHE GENERALI E ASSORBIMENTI
MORSETTIERE
4 x 1,5 mmq
5 x 1,5 mmq
BDB235NO... (HCD401NO...) MTZ80JH4=MT80JH4=23,0 A max. I max.=6,8 A In=0,73 A In tot.=1,24 A 4 x 4 mmq 5 x 6 mmq
MTZ32JF4=MT32JF4=5,9 A max.
MDB235NO463F (GCD401NO463F) 4 x 1,5 mmqI max.=7,1 A In=0,73 A In tot.=1,6 A 5 x 1,5 mmq
MTZ32JF4=MT32JF4=5,9 A max.MDB235NO478F 4 x 1,5 mmqI max.=5,5 A In=0,73 A In tot.=0,73 A 5 x 1,5 mmq
