IMPORTANT read this first!
The operating instructions are an integral part of the product. The instructions contain
important information on the commissioning, usage and operation of the product.
Please read the operating instructions carefully.
The guarantee becomes null and void if the operating instructions are not followed.
Zantingh B.V. cannot be held liable for these damages.
Store this manual carefully near the system!
Contents: Page
1. INTRODUCTION 3
2. REGULATION 3
3. IMPORTANT NOTES 3
3.1 Maintenance 4
3.2 Instruction manual instructions 4
4. SYSTEM COMPONENTS 5
4.1 Burner component 5
4.2 Air fan component 5
4.3 Gas train 5
4.4 Pilot gas line 6
4.5 Control panel 7
4.6 Control switches and reset buttons on the control panel 7
4.7 Frequency control 7
5. START SEQUENCE 8
6. SIEMENS BURNER CONTROL LMV5x OPERATION 10
6.1 AZL display description and operation 11
6.2 Operation 7” touch screen 16
6.3 Settings for limited maximum load via the touch screen 21
7. BURNER FAILURE REPORT 22
8. TROUBLESHOOTING 26
9. SWITCH FROM GAS TO OIL AND BACK (If applicable) 27
11. WARRANTY CONDITIONS 30
