Zanussi ZBB28441SA User Manual

Positioning the door shelves
To permit storage of
food packages of var-
ious sizes, the door
shelves can be
placed at different
heights.
2
1
3
Gradually pull the
shelf in the direction
of the arrows until it
comes free, then re-
position as required.
Helpful hints and tips
Hints for energy saving
• Do not open the door frequently or leave it
open longer than absolutely necessary.
• If the ambient temperature is high and the
Temperature Regulator is set to low temper-
ature and the appliance is fully loaded, the
compressor may run continuously, causing
frost or ice on the evaporator. If this happens,
set the Temperature Regulator toward warm-
er settings to allow automatic defrosting and
so a saving in electricity consumption.
Hints for fresh food refrigeration
To obtain the best performance:
• do not store warm food or evaporating liq-
uids in the refrigerator
• do cover or wrap the food, particularly if it
has a strong flavour
• position food so that air can circulate freely
around it
Hints for refrigeration
Useful hints:
Meat (all types) : wrap in polythene bags and
place on the glass shelf above the vegetable
drawer.
For safety, store in this way only one or two
days at the most.
Cooked foods, cold dishes, etc..: these should
be covered and may be placed on any shelf.
Fruit and vegetables: these should be thor-
oughly cleaned and placed in the special draw-
er(s) provided.
Butter and cheese: these should be placed in
special airtight containers or wrapped in alumi-
nium foil or polythene bags to exclude as much
air as possible.
Milk bottles: these should have a cap and
should be stored in the bottle rack on the door.
Bananas, potatoes, onions and garlic, if not
packed, must not be kept in the refrigerator.
Hints for freezing
To help you make the most of the freezing
process, here are some important hints:
• the maximum quantity of food which can be
frozen in 24 hrs. is shown on the rating plate;
• the freezing process takes 24 hours. No fur-
ther food to be frozen should be added dur-
ing this period;
• only freeze top quality, fresh and thoroughly
cleaned, foodstuffs;
• prepare food in small portions to enable it to
be rapidly and completely frozen and to make
it possible subsequently to thaw only the
quantity required;
• wrap up the food in aluminium foil or poly-
thene and make sure that the packages are
airtight;
6
www.zanussi.com

Zanussi ZBB28441SA Specifications

General

Child lock	-
Door hinge	Right
Product color	White
Built-in display	No
Reversible doors	Yes
Appliance placement	Built-in
Noise level	36 dB
Climate class	SN-T
Total net capacity	268 L
Total gross capacity	280 L
Fridge net capacity	196 L
Fridge gross capacity	205 L
Number of vegetable drawers	2
Fridge number of shelves/baskets	5
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	4 kg/24h
Freezer net capacity	72 L
Freezer gross capacity	75 L
Freezer number of shelves/baskets	3
Connected load	140 W
Energy efficiency class	G
Energy efficiency scale	A to G
Annual energy consumption	358 kWh

Weight and Dimensions

Depth	547 mm
Width	540 mm
Height	1772 mm
Weight	57000 g
Installation compartment depth	550 mm
Installation compartment width	560 mm
Installation compartment height	1780 mm
