Ins
Ins
tr
tr
uctions f
uctions f
or the User
or the User
General information
The official designation of the appliance is home
freezer. According to this the appliance is suitable for
storing frozen and deep-frozen food, freezing
products in quantity given in the user's instructions at
home and making ice.
The appliance can meet the requirements of
standards between different temperature limits
according to the climate class. The letter symbol for
climate class can be found on the data plate.
Description of the appliance, main parts
1. Freezing tray
2. Freezing compartment (with ice tray)
3. Storing compartments (wire baskets)
4. Data plate
5. Switch and indicator unit:
a) Green lamp
b) Red lamp
c) Yellow lamp
d) Continuous-operation (fast freezer)
switch
e) Thermostat knob
6. Defrost water outlet
7. Adjustable feet
8. Door gasket
9. Thermostat
10. Air grid
11. Condenser
12. Air flow
13. Compressor
In figures the TTI 120 F appliance can be seen.
