Page - 26/43 AEXZP0BB - ECO SMART DISPLAY - User Manual
Flow chart showing how to make changes to Option Menu:
1) Opening Zapi Menu
DISP E ZP V0.0
48V 0A 00000
2) Press ROLL UP & SET UP Buttons to enter
CONFIG MENU
% ' %
' ' '
3) The Display will show: SET MODEL
CONFIG MENU
SET MODEL
4) Press ROLL UP or ROLL DOWN until SET
OPTIONS appears
% ' '
% ' '
5) SET OPTIONS menu appears
CONFIG MENU
SET OPTIONS
6) Press ENTER to go into the SET OPTIONS
menu
' % '
' ' '
7) The Display will show the first option
PERFORMANCE TYPE
1
8) Press ROLL UP or ROLL DOWN buttons until
desired option appears
% ' '
% ' '
9) Desired option appears
PERFORM. ENABLE
ON
10) Press SET UP or SET DOWN buttons in order
to modify the value for selected option
' ' %
' ' %
11) New value for selected option appears
PERFORM. ENABLE
OFF
12) Press OUT to exit the menu
' ' '
' % '
13) Confirmation request appears
ARE YOU SURE?
YES=ENTER NO=OUT
14) Press ENTER to accept the changes, or press
OUT if you do not accept the changes
' % '
' ' '
' ' '
' % '
15) SET OPTIONS menu appears
CONFIG MENU
SET OPTIONS
16) Press OUT again. Display now shows the
Opening Zapi Menu
' ' '
' % '
