Zapi EPS-AC0 SWs&ENC - Electrical Specifications; Mechanical Specifications; Basic Release

Page - 8/95 AEMZP0EA - EPS-AC0 SWs&ENC - User Manual
2.3 Electrical specifications
Battery Voltage: .........................................................................Two part numbers:
F07115....................................................................................... 24/36V 50Arms
F07145....................................................................................... 36/48V 45Arms
Maximum current (24/36 V): ........................................................ 50 A (RMS) for 2'
Maximum current (36/48 V): ........................................................ 45 A (RMS) for 2'
Logic Supply current:..............................................................max 200 mA @ 24 V
Minimum Input (key) Supply Voltage after start-up:..........................................12 V
2.4 Mechanical specifications
2.4.1 Basic release
It has Molex Minifit connector with international protection IP54.
EPS-AC0
Figure 2–2
