PrintServer II Installation
Follow these simple steps to install the ZebraNet™ PrintServer II:
1. Turn the printer power OFF, then attach the PrintServer II directly to the Centronics
connector on the printer. Secure the PrintServer II to the printer with the bail wire
locks.
2. Attach an active 10Base-T UTP cable to the receptacle on the back of the PrintServer II.
3. Turn the printer power ON. The Status Indicator will blink orange during the Power
On Self Test and then change to green.
4. Press the Test button on the side of the PrintServer II, or use the configuration utility
provided for your network operating system, to print a Configuration Label.
(A Configuration Label will print automatically if the PrintServer II senses a hardware
error.) Refer to the sample configuration label shown in Figure 6.
NOTE: To successfully print a Configuration Label on the Zebra printer,
it is recommended that a 4” wide x 6” long label be used. If the label is too
small, some information may print outside the label edges.
Software Utilities Installation
A set of four 3.5” floppy disks is included with the ZebraNet™ PrintServer II. The ZebraNet
Software Utilities contained on these disks are used to install the PrintServer II into the
Ethernet network. Follow these simple steps to install the Software Utilities:
NOTE: You must have Administrative Rights on your network to install
most of these utilities.
1. With Windows open, insert Disk 1 and RUN the file called Setup.exe.
2. Follow the directions visible on your monitor as the software is installed.
NOTE: Refer to your printer user’s guide for related information about
printer configuration requirements. Also, see your Network Operating
System documentation for information related to network configuration
and printing operations.
ZebraNet Software Utilities
ZebraNet View for IP and Novell
This utility allows for rapid configuration of all parameters of the ZebraNet PrintServer II.
When the ZebraNet View software launches, it automatically locates all the PrintServer II
2 ZebraNet™ PrintServer II Installation and Operation Guide

Zebra II Specifications

General

Model	Zebra II
Category	Print Server
Connectivity Technology	Ethernet
Data Link Protocol	Ethernet
Network / Transport Protocol	TCP/IP
Management Protocol	SNMP
Operating System Compatibility	Linux, Unix
