Zebra ZM400 Specifications

SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE P/N 14202L REV. 2 04/09/07
Font Matrix Type* Character Size
Inches Millimeters
Height Width Inter-character Gap Height Width Char/inch Height Width Char/mm
A 9 5 1 U-L-D .035 0.020 50.5 0.89 0.50 1.98
B 11 7 2 U .043 0.030 33.7 1.09 0.76 1.32
C,D 18 10 2 U-L-D .070 0.040 25.3 1.78 1.01 0.99
E 41 20 6 OCR-B .160 0.086 11.7 4.06 2.18 0.46
F 26 13 3 U-L-D .101 0.053 18.9 2.57 1.34 0.74
G 60 40 8 U-L-D .234 0.158 6.3 5.94 4.03 0.25
H 30 19 9 OCR-A .177 0.092 10.8 2.97 2.35 0.43
GS 24 24 2
SYMBOL
.094 0.086 11.7 2.38 2.18 0.46
P 20 18 N/A U-L-D .078 .059 N/A 1.98 1.51 N/A
Q 28 24 N/A U-L-D .109 .079 N/A 2.77 2.02 N/A
R 35 31 N/A U-L-D .137 .102 N/A 3.47 2.60 N/A
S 40 35 N/A U-L-D .156 .116 N/A 3.96 2.94 N/A
T 48 42 N/A U-L-D .187 .139 N/A 4.75 3.53 N/A
U 59 53 N/A U-L-D .230 .175 N/A 5.84 4.45 N/A
V 80 71 N/A U-L-D .312 .234 N/A 7.92 5.96 N/A
0 Default: 15 x 12 U-L-D Scalable
*U = Uppercase, L = Lowercase, D = Descenders
Font Matrices for 12 dot/mm (300 DPI) Print heads
Font Matrix Type* Character Size
Inches Millimeters
Height Width Inter-character Gap Height Width Char/inch Height Width Char/mm
A 9 5 1 U-L-D .014 0.010 104.2 0.38 0.25 3.97
B 11 7 2 U .018 0.014 69.4 0.46 0.38 2.65
C,D 18 10 2 U-L-D .029 0.019 52.1 0.76 0.50 1.98
E 82 40 12 OCR-B .131 0.083 12.0 3.44 2.18 0.46
F 26 13 3 U-L-D .042 0.026 39.1 1.09 0.67 1.49
G 60 40 8 U-L-D .096 0.077 13.0 2.52 2.02 0.50
H 60 38 18 OCR-A .096 0.090 11.2 2.52 2.35 0.43
GS 24 24 2
SYMBOL
.038 0.042 24.0 1.01 1.09 0.92
P 20 18 N/A U-L-D .032 .029 N/A 0.84 0.76 N/A
Q 28 24 N/A U-L-D .045 .038 N/A 1.18 1.01 N/A
R 35 31 N/A U-L-D .056 .050 N/A 1.47 1.30 N/A
S 40 35 N/A U-L-D .064 .056 N/A 1.68 1.47 N/A
T 48 42 N/A U-L-D .077 .067 N/A 2.02 1.76 N/A
U 59 53 N/A U-L-D .094 .085 N/A 2.48 2.23 N/A
V 80 71 N/A U-L-D .128 .114 N/A 3.36 2.98 N/A
0 Default: 15 x 12 U-L-D Scalable
*U = Uppercase, L = Lowercase, D = Descenders
Font Matrices for 24 dot/mm (600 DPI) Print head
Bar Code Symbologies & Specifications
(ZPL Only, Other Firmware Languages may vary)
• Bar code modulus "X" dimension:
- Picket fence (non-rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.3 mil to 33 mil
600 dpi = 1.6 mil to 16 mil
- Ladder (rotated) orientation:
203 dpi = 4.9 mil to 49 mil
300 dpi = 3.9 mil to 39 mil
600 dpi = 1.6 mil to 16 mil
• Bar code ratios – 2:1 to 3:1 in supported symbologies
• Aztec
• Codabar (supports ratios of 2:1 to 3:1
• CODABLOCK
• Code 11
• Code 16k
• Code 39 (supports ratios of 2:1 to 3:1
• Code 49 (2-D)
• Code 93
• Code 128 (subsets A, B, C, and UCC case C codes)
• Data Matrix
• EAN-8, EAN-13, EAN extensions
• Interleaved 2 of 5 (supports ratios 2:1 to 3:1, modulous10
check digit)
• Planet Code
• Logmars
• MaxiCode (2-D)
• PDF417 (2-D)
• Micro PDF (2-D)
• Plessy
• Postnet
• QR-Code
• MSI
• Standard 2 of 5
• Industrial 2 of 5
• UPC-A, UPC-E, UPC extensions
• RSS
• TLC 39
Zebra Programming Language
®
(ZPL
®
and ZPL II
®
)
• Communicates in printable ASCII characters
• Compatible with mainframe, mini, and PC hosts
• Downloadable objects include graphics, scalable and bitmap
fonts, label templates and formats
• Data compression
• Automatic memory allocation for format while printing
• Automatic serialization of fields
• Format inversion (white on black)
• Mirror-image printing
• Four position field rotation (0º, 90º, 180º, 270º)
• Slew command
• Programmable label quantities with print, pause, cut control
• Status messages to host upon request
• Unicode compliant
Supports UTF-8 and UTF-16
Natively supports bidirectional and complex scripts
Support for OpenType Glyph Substitution

Zebra ZM400 Specifications
