Zebra ZQ320 User Manual

2
ZQ300 Series User Guide
continued
Table of Contents
Proprietary Statements ..............................................................4
Document Conventions .............................................................. 6
Introduction to the ZQ300 Series .............................................. 7
Unpacking and Inspection ............................................................... 8
Reporting Damage ........................................................................... 8
ZQ300 Series Technology ........................................................... 9
PowerPrecision+Battery ...............................................................................9
Direct Thermal Printing ..............................................................................10
Thermal Shutdown .....................................................................................10
Near Field Communications (NFC) ............................................................10
QR Code ......................................................................................................11
Made for iPhone (MFi) ................................................................................11
Features Overview ..................................................................... 12
Getting Ready to Print .............................................................. 13
Battery ............................................................................................. 13
Installing/Removing Battery & Battery Tape Insulator ...............................13
Battery Tape Insulator .................................................................... 14
Battery Safety ................................................................................. 16
Charger Safety .............................................................................................16
Charging the Battery ................................................................. 17
AC-to-USB Adapter .....................................................................................17
1-Slot Battery Charger ................................................................................18
3-Slot Battery Charger ................................................................................19
Charging Temperature ...............................................................................19
1-Bay Docking Cradle .................................................................................20
5-Bay Docking Cradle .................................................................................21
Vehicle Adapter ..........................................................................................22
ZQ300 Series Media ....................................................................... 23
Designing Labels .........................................................................................24
Using Pre-Printed Receipt Media .................................................. 25
Loading the Media ......................................................................................30
Media Spacers .............................................................................................31
Operator Controls .......................................................................... 32
Forced Download Description and LED Behavior .....................................37
Power Save Mode .......................................................................................39
Draft Mode ...................................................................................................39
Verify the Printer Is Working ......................................................... 40
Cable Communication .................................................................................41
Wireless Communications with Bluetooth .................................................44
Bluetooth Networking Overview ................................................................44
NFC Use Cases ............................................................................................47
WLAN Overview .............................................................................48
Setting Up the Software ................................................................ 49
Wearing the Printer ...................................................................50
Belt Clip ........................................................................................................50
Adjustable Shoulder Strap ..........................................................................51
Soft Case......................................................................................................52
Preventive Maintenance ...........................................................53
Extending Battery Life ................................................................... 53

Zebra ZQ320 Specifications

General

Display	No
Product color	Black
International Protection (IP) code	IP54
Flash memory	256 MB
Internal memory	128 MB
Built-in barcodes	2D
Page description languages	ZPL
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Media thickness	0.06 - 0.16 mm
Maximum roll diameter	40 mm
Windows operating systems supported	Yes
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.0
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	72 mm
Battery voltage	7.2 V
Battery capacity	2280 mAh
PC connection	USB 2.0
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	130 mm
Width	117.7 mm
Height	49.5 mm
Weight	430 g
