1019 I H- 5120VN D
13
Introduction
Communication Interfaces
Communication Interfaces
The communication interface connectors are shown in Figure 2. A ZebraNet wireless print
server option may also be present on your printer. You may send label formats to the printer
through any communication interface that is available on your printer.
For detailed information about the types of connections available, see Communication
Interface Specifications on page 214.
For instructions on when and how to connect your computer to one ore more of these
communication interfaces, see Install the Printer Driver and Connect the Printer to the
Computer on page 62.
Figure 2 • Location of Communication Interfaces
Internal wired Ethernet print server
Serial port
USB port
Parallel port (optional)

Other manuals for Zebra ZT400 Series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra ZT400 Series and is the answer not in the manual?

Zebra ZT400 Series Specifications

General IconGeneral
Storage Temperature-40°F to 140°F (-40°C to 60°C)
Humidity20% to 85% non-condensing
Print Width4.09 in (104 mm)
Print Resolution203 dpi
Max Print Speed14 ips (356 mm/s)
Media SensorsTransmissive and reflective
ConnectivityUSB 2.0, Serial RS-232, 10/100 Ethernet, Bluetooth 4.1
Memory256 MB RAM, 512 MB Flash
Media Width4.5 in./114 mm
Media Length39 in (991 mm)
Ribbon Length450 m
Supported Media TypesContinuous, die-cut, notch, black-mark
Operating Temperature40°F to 104°F (5°C to 40°C)
Power Requirements100-240 VAC, 47-63 Hz
Dimensions19.50 x 10.75 inches (495 x 274 mm)
