Parts / Diagrams
Humphrey Field Analyzer 3 Service Manual 21 2660021151225 A
Abbreviation Definitions
Table 1 lists definitions for the abbreviations that appear in the following
pages.
Table 1. Abbreviation Definitions
Printed Circuit Board Assembly
Electro Magnetic Interference
Motorized Patient Support
Note - The drawings on the following pages provide illustrated parts
breakdowns of the instrument. The parts drawings are keyed by item
numbers to their associated parts lists.
For part numbers of individual cables, first refer to the System Interconnect
diagrams at the end of this service manual. Cables that do not have a part
number listed are supplied only as part of an associated assembly.
Note - Part numbers are not provided to parts that are NOT identified as a
“Spare Part”.
