3. HEATLESS DRYER NOMENCLATURE
NOMINAL
FLOW
SCFM* TYPE / DESIGN SERIES ELECTRICAL POWER OPTIONS
20 MPS = Small Pressure Swing 1 = 115-1-60 (150 PSIG)
30 3 = 115-1-60 (300 PSIG)
40 A = Pneumatic (150 PSIG)
60 B = Pneumatic (300 PSIG)
0 = No Options 0 = NEMA 1 (-40°) 0 = Standard 0 = No Filter Pkg
B = F + H B = NEMA 1 (-80°) B = S + M V = Filter Pkg A
F = Fail-To-Shift L = NEMA 1 (-100°) M = Moisture Indicator 3 = Filter Pkg B
H = High Humidity H = NEMA 4 (-40°) P = Adjustable Purge 6 = Filter Pkg C
M = Moisture Load Control + F K = NEMA 4 (-100°) Q = P + M 7 = Filter Pkg D
N = M + H D = NEMA 12 (-40°) R = Repress Line 5 = Filter Pkg E
V = N.O. Inlet Valves F = NEMA 12 (-100°) S = Safety Relief Valves 4 = Filter Pkg F
9 = Filter Pkg A with Bypass
* Nominal Flows indicated are for 100°F inlet air temperature, 100°F ambient temperature
and 100 psig compressed air pressure.
Nomenclature shown above represents standard price sheet options. Other options are
available. Refer to nomenclature insert specific to your dryer for details.
