Zenith B27A24Z - Factory Menu Recommended Settings

CM151 2-3 CA - INSTALLER MENUS
INSTALLERS MENU 221-1384 (continued)
CA CONSUMER CHASSIS
FACTORY MENU RECOMMENDED SETTINGS
ITEM RANGE 25” 27” DESCRIPTION
00 F MODE 0-1 0 0 Factory mode - perfer to page 2-1
01 PRE PX 0-1 0 0 Used to store customer menu adjustments
02 V POS 0-24 13 13 Moves On Screen display vertically
03 H POS 0-20 6 6 Moves On Screen display horizontally
04 LEVEL 0-1 1 1
05 BAND 0-7 0 0 Broadcast Band adjustment
06 AC ON 0-1 0 0 AC power feature
TECHNICAL SETTINGS
07 RFB PF 0-1 1 1 Control for brightness in therefore mode
08 3.5T 0-1 0 0 3.58 MHz Trap
09 RF BRT 0-63 33 33 Control for brightness in RF mode
10 AX BRT 0-63 33 33 Control for brightness in AUX mode
11 MAX CON 0-63 63 63 Control for contrast
12 VSIZE 0-63 145 125 Vertical Size
13 HSIZE 0-254 0 0 Horizontal size
14 V PHASE 0-7 2 2
Shifts picture vertically
15 H PHASE 0-31 14 14 Shifts picture horizontally
16 AUDLVL 0-63 46 46 Sound Attenuation
17 RF AGC 0-63 31 31
Weak channel adjustment
18 H AFC 0-1 1 1 Horizontal Automatic Frquency control
19 WHCOMP 0-1 0 0 White compression
20 60HZSW 0-2 2 2 60 Hertz Switched
21 PIFVCO 1-127 31 31 PIF Voltage Controlled Oscillator
COLOR TEMP STARTING VALUE
22 R CUT 0-254 0 0 B&W tracking adjustment
23 G CUT 0-254 0 0 B&W tracking adjustment
24 B CUT 0-254 0 0 B&W tracking adjustment
25 G GAIN 0-254 103 103 B&W tracking adjustment
26 B GAIN 0-254 75 75 B&W tracking adjustment
27 CTYPE 0-3 2 2 Chasis type
28 SCROLL 0-1 0 0 User Menu scroll type
29 KEYS 0-1 0 0 Keyboard type
AUDIO SETTINGS
30 SPKRSW 0-1 0 0 Internal Speaker Switch
31 SURF 0-1 0 0 Surf Mode
32 A ATT 0-15 9 9 Audio Attenuator
33 ASPECTRAL 0-63 31 31 Adjustment of Stereo seperation
34 WBAND 0-63 31 31 Wide band Low Frequency Seperation
