1-800-892-3986 IS19172-I2
Cleaning Note:
Cleaning with a dry cloth may be sufcient, but for other stains or marks wipe gently with a damp cloth.
DO NOT use strong detergents or abrasive cleaners, they may damage the surface of this product.
Tools Needed -
not included
List of Parts - NOTE: Product is marked for TENSION INSTALLATION.
Before assembling,
Make sure that the tube assemblies (B) are at the shortest position by twisting the end of the tubes in
the OPPOSITE DIRECTION of the arrow stickers.
A 1 in. Mounting Bracket 1
A End Cap 1
A 1 in. Diameter Tube 1
B 7/8 in. Mounting Bracket 1
B End Cap 1
B 7/8 in. Diameter Tube assembly 1
B
B
B
A
A
A
LEFT SIDE (A)
RIGHT SIDE (B)
List of Hardware -
Hardware packed in bags.
Mounting Screw
x 4
C
Wall Anchor
x 4
D
Allen Wrench
x 1
E
Set Screw
(2 pre-installed)
x 4
F
Set Screw Cap
x 2
G
