7
1-800-892-3986 IS19172-I2
Step 2 - Permanent Installation
• Align the top hole of the left mounting bracket (A) to the top wall anchor (D) that is now in the wall.
• Rotate a pencil through the bottom hole of the left support to mark drilling location. NOTE: MAKE SURE THE
CENTER DIVIDER IS PERFECTLY HORIZONTAL AND SCREW HOLES ARE POSITIONED VERTICALLY.
• Drill the bottom hole where marked. With your hammer, gently tap the wall anchor (D) into the hole all the
way so the edge is ush to the wall.
• Repeat on the other side with the right mounting bracket (B).
x
x
D
A
To Next Page
