For safe operation and maintenance, symbols are
carved in relief on the machine. According to these
indications, please be careful not to take a mistake.
(a) The port to refuel the "MIX GASOLINE"
Position: FUEL TANK CAP
(b) The direction to close the choke
Position: AIR CLEANER COVER
(c) The direction to open the choke
Position: AIR CLEANER COVER
2. Symbols on the machine
3. Specifications
MODEL CODE Unit BC4350FW
Overall size
Length mm 1845
Width mm 650
Height mm 560
Dry weight Kg 7.8
Engine model ✽ G45L-F
Displacement cc 41.5
Carburetor ✽ Float
Fuel (Mixture ratio) ✽ 50:1 (Gasoline and 2cycle oil)
Fuel tank capacity litter 0.8
Service range rpm 5000~8000
Spark plug ✽ Champion RCJ6Y
Clutch system ✽ Two-shoe Centrifugal-Type
Anti-vibration system
Housing ✽ Yes
Handle-bracket ✽ No
Gearhead
Neck angle deg 60
Reduction ratio ✽ 1.400
Blade rotation ✽ Counter-clockwise
Handle type ✽ Double
Throttle lever ✽ Trigger Type (With Safety-lock)
Standard cutter ✽ 2 Teeth Blade
Harness type ✽ Double
Quick release ✽ Yes
Standard accessories
Fuel-Tank ✽●
Tool-kit ✽●
Owner's manual ✽●
Specifications are subject to change without notice.
