Page 10 of 15
Part List：
：：
：
1
．
Cutting Blade
2
．
Counter Bade
3
．
Blade Adjustment Gear Clip
4
．
Trigger Guard
5
．
Trigger
6
．
Handle Grip
7
．
Battery Connector
8
．
Pruner Battery Wire
9
．
Battery
10
．
Battery Charger
11
．
Blade Cutting Size Adjustment Button
Specifications
：
Specifications
Pruning Shear
1 Max cutting diameter SCA2: 1.1-inch/Green
SCA3: 1.5-inch/Green
2 Rated voltage DC 36.0V
3 Rated power 300 W
4 Rated current 10.0 A
5 Current protection
≥
40A
6 Class II
7 Weight 1.9lbs, 0.9 Kg
Lithium Battery
1 Capacity 4.4 Ah
2 Voltage 36.0V
3 Running time 12.0 hours
4 Weight 3.3lbs, 1.5kg
Battery Charger
1 Rated voltage 100-240V AC ,50-60Hz
2 Output voltage DC41.5V
3 Charging current 1.0A
4 Class II
Ⅱ
5 Charging time 4.5 hours
