Monsoon I Use, Care, and Installation Guide
ZEPHYRONLINE.COM
Installation Instructions
Horizontal Ducting Preparation
AK9228BS & AK9234BS Models Only
13. Secure blower to captive nuts on
interior back wall of liner with (8)
3/16” x 3/8” screws, (4) screws
for each bracket. Seal any gaps
around the knock-out plate by
using certified aluminum duct
tape. Plug in blower molex plug.
Horizontal ducting preparation is now
Horizontal ducting preparation is now
complete. Refer to Page 18, Step 5 to
complete. Refer to Page 18, Step 5 to
complete installation.
