Zephyr Monsoon Connect User Manual

36
Monsoon Connect Use, Care, and Installation Guide
MONSOON
CONNECT
INSERT
CORE
Wiring Diagram
Black
White
Red
Black
Green
White
Black
Body
White
Black
LED
LED
WIFI
Green
Body
Motor
ANT
AK9428BS, AK9434BS, AK9440BS
Wiring Diagram
WIFI
WHITE
B/W
BLACK
BLACK
BLACK
BLACK
BLACKBLACK
BLACK
B/W
WHITE
WHITE
WHITE
WHITE
WHITE
GREEN
BODY
MOTOR-1
MOTOR-2
WHITE
K
Single Blower
Dual Blower
A. Wi-Fi connection wire
C. Power wire for expansion PCB
D. Power wire for expansion PCB
E. Blower connection wire
F. Blower connection wire
G. Control connection wire
H. Dual blower PCB to switch wire
I. Power lead
J. Dual blower connection wire
K. Blower connection wire
