Monsoon Connect Guide d’utilisation, d’entretien et d’installation
INSÉRER
CORE
MONSOON
CONNECT
Instructions d’installation
¯Ů
Vue de dessus
Vue 3/4
Vue arrière
(30 po) 11- 3/16 po
(36 po) 14- 3/16 po
(42 po) 17-
3/16 po
(48 po) 17-
7/8 po
(30 po only) 5-9/16 po (36 po, 42 po, 48 po) 6-1/8 po
L/C
(30 po) 9-1/4 po
(36 po) 11-7/8 po
(42 po) 14-7/8 po
(48 po) 17-7/8 po
2 po
entrée defoncable
10-3/8 po
entrée defoncable
L/C
5-
1/2
po
7- 11/16 po
12 po
1
9
-3/8
p
o
12
p
o
3 po
antenne à
distance
Ø *7-
11/16
po
** 9-15/16 po
*9-1/2 po
**14-3/16 po
*8-1/16 po **10-3/8 po
(30 po) 22-3/8 po, (36 po) 28-3/8 po,
(42 po) 34-3/8 po, (48 po) 40-1/4 po
(30 po) 28-3/8 po, (36 po) 34-3/8 po,
(42 po) 40-3/8 po, (48 po) 46-1/4 po
(30 po) 9-1/4 po
(36 po) 11-7/8 po
(42 po) 14-7/8 po
(48 po) 17-7/8 po
* 8 po conduit rond
** 10 po conduit rond
