Installation – Recirculation Option
DUCTLESS RECIRCULATING (OPTION)
Ductlessrecirculatingisintendedforapplicationswhereanexhaustductworkisnotpossibletobeinstalled.
When converted, the one piece liner functions in air “purifying” mode rather than exhausting the air. Fumes
andexhaustfromcookingisdrawnandlteredbyacharcoallter.Theairisthenpuriedandrecirculated
backintothekitchen.
Werecommendtoalwaysexhaustairoutsideofthehomebyemployingexistingorinstallingnewductwork,
ifpossible.Thelinerismoste󰀨ectiveande󰀩cientasanexhaustunit.Onlywhentheexhaustoptionisnot
possible should you use the liner in recirculating mode.
Whenconvertedtorecirculatingmode,acharcoallterisrequiredtobeinstalledontopofthemeshlterand
areturnairventisneededtodirectairbackintothekitchen.Themeshlterisintendedtocaptureresidue
fromcookingandthecharcoallterhelpstopurifyfumesexhaustedfromcookinginrecirculatingmode.
Purchaserecirculatingkitasfollows.
Part No. Qty. to Order
ZRC-9100A 1
Charcoalltersarenotwashableandmustbereplacedapproximatelyevery3monthsbasedo󰀨anaverage
usage of 1 hour a day.
Orderreplacementcharcoalltersasfollows:
Part No. Qty. to Order
Z0F-C091 2
For detailed installation instructions please refer to manual included with recirculating kit.
Return Air Vent
top of cabinet
