Installation – Ducting Preparation
Note: If using hood in recirculating mode skip these steps and turn to page 12.
Vertical Ducting
(7"Round)
Vertical Ducting
(3-1/4"x10"Rectangular)
1.Usingaat-headscrewdriver,removeboththe
rectangularandroundknock-outplateslocatedon
top of hood
1.Usingaat-headscrewdriver,removeonlythe
rectangularsectionoftheknock-outplatelocated
on top of hood.
1.Usingaat-headscrewdriver,removethe
rectangularknock-outplatelocatedonbackof
hood.
2.Secure3-1/4"x10"rectangularcollartotopof
hoodusing(6)M4x6screws.
2.Secure3-1/4"x10"rectangularcollartobackof
hoodusing(6)M4x6screws.
2.Secure7"roundcollartotopofhoodusing
(6)M4x6screws.
Horizontal Ducting
(3-1/4"x10"Rectangular)
