11
Installation – Hood Specication ZRE
FRONT SIDE
TOP of HOOD TOP SUPPORT FRAME
(top view)
10
3/8
23
15/16
35
3/16
25
9/16
24
1/2
3
9/16
10
7/8
2
3/4
11
5/8
4
3/8
(top of electrical box)
13
3/4
5/16
C/L
6”
8”
8 3/4
8 1/4
3
3/4
4
3/16
5/8
elec. k/o
STANDARD
min. ducted - 28 1/2”
min. recirc. - 28 1/2”
max. - 38”
Z1C-01REBS EXTENSION
min. ducted - 48 1/2”
min. recirc. - 48 1/2”
max. - 78”
