INSTALLATION
6
MOUNTING THE RANGEHOOD
9. Fasten mounting screws into
underside of mounting location,
and reposition hood into place.
10. Hang hood onto mounting screws and
hand tighten.
11. For ductless conversion, the interior cover
plate must be unscrewed, repositioned
and re-screwed into alternate position
as shown.
12. Reinstall the filter panels.
Cover panel position
for duct exhaust
Cover panel position
for ductless conversion
