Wiring Diagrams
VOLTS
HZ
MAX AMPS
120 60 3.5
USE ONLY TYPE MR16, GU10, 50 W. MAX. HALOGEN LIGHT BULBS.
ZSA-E30CS, ZSA-M90CS
ZSA-E30CB, ZSA-M90CB
ZSA-E30CW, ZSA-M90CW
Power consumption shown for default 685 CFM blower confi guration
ACT 390 CFM - Fan Max. 300W @ 2.6A
ACT 290 CFM - Fan Max. 289W @ 2.4A
