VOLTS
HZ
AMPERES
MAXIMUM
120 60 3.5
ZSA-E30CS, ZSA-M90CS
ZSA-E30CB, ZSA-M90CB
ZSA-E30CW, ZSA-M90CW
UTILISER SEUL TYPE MR16, GU10, 50 W. MAX. LES AMPOULES HALOGENES
SCHEMA DE CIRCUIT
MOTEUR
BLANC
BLANC
BLANC
BLANC
ROUGE
ROUGE
ROUGE
JUANE
JUANE
JUANE
JUANE
JUANE
GRIS
GRIS
BRUN
BRUN
BLEU
BLEU
VERTE
VERTE
ROUGE
NOIR
NOIR
Schéma de câblage
16
