Zero 88 FLX - ZerOS Server; Mounting ZerOS Server; ZerOS Wing

Dimensions
68mm (H) x 461mm (W) x 284mm (D)
Weight
4 kg
Operating temperature range
+5 to +40 °C
Humidity
5% to 95% non-condensing
ZerOS Server
Dimensions
43.6mm (H) x 482.6mm (W) x 226.5mm (D)
Weight
3.8kg
Operating temperature range
+5 to +40 °C
Humidity
5% to 95% non-condensing
Mounting ZerOS Server
ZerOS Server is designed to be rack mounted into a standard 19” cabinet using 4 x M6 Cage Nuts and 4 x M6 x
16mm screws.
Ventilation must be provided in the rack such that ZerOS Server can freely draw air from its rear ventilation slots.
ZerOS Wing
Zero 88 - ZerOS - Page 231 of 233 Printed: 23/11/2020 12:50:03 JH
