General Operation
4.13
Factory Supplied Front Suspension Settings
The following information will allow you to adjust the front
suspension back to the factory settings the motorcycle was
originally supplied with.
FX Model
FXE and FXS Models
ADJUSTMENT SETTING
Front Fork Compression 5 clicks counter-clockwise from
maximum (H) position.
Front Fork Rebound 9 clicks counter-clockwise from
maximum (H) position.
Front Fork Preload 7.5 turns clockwise from the full out
position.
ADJUSTMENT SETTING
Front Fork Compression 7 clicks counter-clockwise from
maximum (H) position.
Front Fork Rebound 12 clicks counter-clockwise from
maximum (H) position.
Front Fork Preload 5.5 turns clockwise from the full out
position.
Zero Owner's Manual (FX and FXS).book Page 13 Thursday, May 13, 2021 10:53 AM
